1.1 Product Overview
The IDH28 integrated pulse type open-loop stepper driver is a newly launched new type of motor drive integrated motor driver. It adopts the latest dedicated motor control digital signal processor to improve the comprehensive performance of the motor, reduce the heat generation and vibration of the motor. It adopts an integrated design of motor and driver, with a more compact installation and reduced external interference.
IDH28 comes with serial port debugging function and communication adopts MINI USB interface. Users can set various parameters such as subdivision, current, and working mode through PC based upper computer debugging software, greatly enriching the practical functions of the product and meeting the needs of the vast majority of applications.
1.2 Product Features
● Integrated motor and drive, saving wiring labor
● Small size, easy to install
New generation 32-bit DSP technology with excellent stability, strong compatibility, and high cost-effectiveness
● Optical isolation differential signal input
Built in fine particles, excellent low-speed stability
The pulse response frequency can reach up to 200KHz (higher can be adjusted)
● Subdivision setting range of 200-60000 (any fine subdivision can be set through the upper computer)
Precision current control significantly reduces motor heating
Low vibration and low noise
● Equipped with overvoltage, undervoltage, and phase loss alarm protection functions
● Input voltage range: DC12V~40V
The default effective current is 1.0A (any current value can also be set through the upper computer)
1.3 Application Fields
Suitable for various small and medium-sized automation equipment and instruments, such as medical equipment, testing equipment, marking machines, plotters, etc. Meet customers' requirements for low noise, low heat generation, convenient wiring, and stronger anti-interference.
