| Standard closed-loop motor straight out cable 3 meters | |||||||||
| Seat number | Standard model | Corresponding to the Lesai naming method model | Current（A） | Shaft diameter（mm） | axis length(mm) | Motor lead length(M) | Holding torque（N▪m） | Long body（mm） | Remark |
| 42 | GR42HS48-3M | 42CME06-3M | 2.0 | 5.0 | 24.0 | 0.3 | 0.6 | 48 | None |
| GR42HS60-3M | 42CME08-3M | 2.0 | 5.0 | 24.0 | 0.3 | 0.8 | 60 | None | |
| 57 | GR57HS56-3M | 57CME13-3M | 4.0 | 8.0 | 21.0 | 3.0 | 1.3 | 56 | Straight out 3 meters of 8 million times high-flexible line |
| GR57HS80-3M | 57CME24-3M | 5.0 | 8.0 | 21.0 | 3.0 | 2.4 | 80 | Straight out 3 meters of 8 million times high-flexible line | |
| GR57HS80-30-3M | 57CME24-30-3M | 5.0 | 8.0 | 30.0 | 3.0 | 2.4 | 80 | Straight out 3 meters of 8 million times high-flexible line | |
| 60 | GR60HS86-3M | 60CME30-3M | 5.0 | 8.0 | 21.0 | 3.0 | 3.0 | 89 | Straight out 3 meters of 8 million times high-flexible line |
| GR60HS86-30-3M | 60CME30-30-3M | 5.0 | 8.0 | 30.0 | 3.0 | 3.0 | 89 | Straight out 3 meters of 8 million times high-flexible line | |
| 86 | GR86HS80-3M | 86CME45-3M | 6.0 | 14.0 | 32.0 | 3.0 | 4.5 | 80 | Straight out 3 meters of 8 million times high-flexible line |
| GR86HS118-3M | 86CME85-3M | 6.0 | 14.0 | 32.0 | 3.0 | 8.5 | 118 | Straight out 3 meters of 8 million times high-flexible line | |
| GR86HS155-3M | 86CME125-3M | 6.0 | 14.0 | 32.0 | 3.0 | 12.0 | 155 | Straight out 3 meters of 8 million times high-flexible line | |
