Product Feature
●Small size, easy to install
●The brake output control interface is reserved, and the relay intermediate control is not required
●The new generation of 32-bit DSP technology has good stability, strong compatibility and high cost performance
●External dip sets drive segmentation, initial direction, alarm polarity, algorithm, smoothing factor
●Optical isolation of differential signal input
●Built-in micro division, low speed stability is excellent
●Pulse response frequency up to 200KHz (higher can be changed)
●Subdivision setting range 400-60000(can be set by the host computer)
●Precision current control greatly reduces motor heating
●Low vibration and low noise
●It has alarm protection functions such as overpressure and overdifference
●Input voltage range： DC 24V~50V / AC 18V~36V
application area
Suitable for a variety of small and medium-sized automation equipment and instruments, such as: engraving
machine, marking machine, cutting machine, plotter, CNC machine tools, automatic assembly equipment. The
application effect is especially good in equipment applications where users expect low noise and high speed.
